| ENGINE |
|
| Type |
4-stroke, liquid-cooled, DOHC, 5-valve,
Parallel four cylinder |
| Displacement |
749.0 cc |
| Bore
and stroke |
72.0 x 46.0 mm |
| Compression
ratio |
11.5 : 1 |
| Max.
power (DIN) |
125 PS (92 kW) @11,000 rpm |
| Max.
power (ISO) |
119 PS (87 kW) @11,000 rpm |
| Max.
torque |
7.1 kg-m (69.6 Nm) @ 9,000 rpm |
| Lubrication |
Wet sump |
| Carburation |
(R) Mikuni BDST38/4 |
| Ignition |
T.C.I. (Digital) |
| Starter
system |
Electric |
| Fuel
tank capacity |
19 litres |
| Oil
tank capacity |
4 litres |
| Transmission |
6- speed |
| Final
transmission |
Chain |
| CHASSIS |
|
| Overall
length |
2,160 mm |
| Overall
width |
730 mm |
| Overall
height |
(R) 1,165 mm |
| Seat
height |
770 mm |
| Wheelbase |
1,420 mm |
| Min.
ground clearance |
140 mm |
| Dry
weight |
(R) 196 kg |
| Dry
weight |
(R) 196 kg |
| Front
suspension |
Telescopic fork |
| Rear
suspension |
Swinging arm (Link Suspension) |
| Front
brake |
Dual disc, 320 mm diameter |
| Rear
brake |
Single disc, 245 mm diameter |
| Front
tyre |
120/70 ZR17 |
| Rear
tyre |
180/55 ZR17 |
Motor is wel gechipt !!!!
|
